Intro

A while ago I published a post explaining the setup of the Quizzing Master slides, compulsory parts of each theme, even the almost empty Blank theme. In this article I will try to explain my experiences using Fluid Boxes on Content Master slides. Most themes shipped with Captivate have several content master slides (exception = Blank theme). Let us first start with the master slides that are not behaving like the content or quiz master slides.

Main master slide, Blank and Title master slides

Main Master slide

It is not possible to insert Fluid boxes on the main master slide: the button seems active but both options (Vertical and Horizontal) are dimmed. Objects placed on that Main master slide, and inherited by the daughter master slides, are to be set up using the Position Properties panel. Example: the text container with my name and copyright in the example movie.
As you probably know, it is not possible to have shape buttons timed for the rest of the project when you use Fluid boxes. You could put a shape button on the main or one of the other master slides but you cannot control it because it has no ID. In the example movie I preferred to have a Next button on the individual slides, because ton most slides it is hidden until the learner has visited everything. However a toggle shape button for Audio, for CC, for the TOC could be on the Main Master slide. They will not behave like objects in a Fluid box however, but act as defined on the Position Properties panel for size and location.

However after some more testing on iOS devices, the Position properties set up for those objects are not correctly displayed in portrait mode.

TIP: at this moment avoid putting objects on the Main master slide (except background of course), since they don’t display at the correct location on some mobile devices.

Blank Master slide

This master slide has no Fluid boxes by default but you could add them. As I have explained in previous articles, you should prefer to duplicate the master slide for editing, don’t edit the original slide because it is used for Powerpoint import and for software simulations.

Title Master slide

That master slide has one Fluid box (parent fluid box) but no child fluid boxes. It is set up as ‘Squeeze in a Column’, and vertically and horizontally centered. Since the Title Placeholder is inserted directly in this Parent Fluid Box, you are not able to add child fluid boxes.  Because each new project, using the default theme White will start automatically with a Title slide, this has caused already many frustrations when starting with the use of Fluid boxes. If you want to use fluid boxes on the first slide, you have to change the master slide from Title to Blank (exception Blank theme which starts with a Blank slide).

TIP: if you want to add objects on the Title master slide, first take out the Title Placeholder, to be able to insert child fluid boxes. Then put back the Title Placeholder in one of the child fluid boxes.

Content master slides

It can be a time saver to use a content slide that has already Fluid boxes. In a future next article I’ll explain how to create a custom content master slide with the help of Guides, but for now let us focus on an existing master slide, and see how we can tweak it.
In the example movie, the second slide is based on the Content04 master slide from the Theme ‘OldPaper’. I didn’t customize the theme, just applied the correction explained in my last post

Look at the setup of the Fluid boxes on the master slide: the parent fluid box (FB_15) has two vertcial child FB’s (FB_16 and FB_17). The top one is meant for the Title placeholder:

The bottom Fluid Box has 4 child FB’s, (FB_19,FB_20, FB_21, FB_22), which are set up to wrap Symmetrically (when width is too small, two FB’s will move to the next row), and have a padding both vertically and horizontally to have some spacing between the FB’s. Each of them has a placeholder for an image.

Example movie

Play with this responsive movie (will open in a new window) which has only 3 slides: Title slide (with inserted Next button, and taking over my name from the main master slide), a slide based on Content04 master slide, with a lot of tweaking, and an End slide. On the content slide you are supposed to click each of the 4 buttons in the top. The Next button on that slide will only appear when you have clicked all available shape buttons and seen all the content.

Refining slide based on Content master slide

The FB setup on the master slides can be tweaked on a slide based on that master slide. You can remove all fluid boxes, but that has not much sense. To demonstrate I did a lot of tweaking for the second slide of the movie which you just watched:
  • I deleted the image placeholders
  • I decreased the height of the top fluid box (FB_MS2_16) to 10%, originally it was 15% (edited font style as well)
  • I added a third vertical child FB under the parent FB_MS2_15, it is labeled FB_9

    TIP: changes like this will not affect the master slide. You can get the original layout from the master slide back by using the ” Reset Master Slide” button in the Properties panel of the slide.

  • That last FB_9 got two horizontal FB’s, FB_37 (70% of the width) and FB_38 (30% of the width); the last one will be used for the navigation buttons (Back/Next)
  • The setup for FB_38 is visible in this screenshot
  • Each of the four FB’s in the center (FB_19,FB_20, FB_21, FB_22) has no longer any object (see 1) and can be divided in two new vertical child FB’s
  • As you can see on the screenshot, the top FB will have a shape button and explanation text (originally hidden, but cannot be grouped in FB’s what would make the advanced actions a lot easier), the bottom one has an example of the style of that state in a shape (also initially hidden).
  • Setup for the top FB’s here is visible in this screenshot; for the Shape button (‘Normal’) the option Maintain Aspect Ratio is kept, but not for the Text container, so that it can change for smaller screen sizes (especially in portrait mode).

More questions?

You will have seen that I always had Rulers and Guides activated. My next blog post will focus on the use of that great tool, which almost no one seems to use?

Sure, I have several advanced actions in that movie, but that was not the goal of this post. No explanations here about those actions.
